Made for makers The new ZEISS T-SCAN hawk with GOM Inspect Suite

Intro Highlights GOM Inspect Suite Features Applications Video Teaser Technical Data Contact Click to navigate Seeing beyond

Your portable solution for 3D scanning and easy inspection The newT-SCAN hawk is portable, precise and made to make a difference: In combination with the pre-installed software GOM Inspect Suite, the powerful solution assists you along every step of your task. From scanning high quality 3D data to delivering high quality results. It's made to simplify processes. It's made for you.

Made to be portable The new T-SCAN hawk is designed to capture data wherever it is needed. The lightweight hand-held solution supports you in production or on site, from reverse engineering to quality control.

Made to be precise The portable 3D laser scanner includes impressive technical features such as photogrammetry of large objects, multiple laser sources and three scanning modes even for fine details or deep pockets - all to deliver 3D measurement data with the highest precision.

The new T-SCAN hawk with pre-installed GOM Inspect Suite is a complete solution to simplify your entire workflow from scanning to evaluation and reporting.

Making quality visible GOM Inspect Suite GOM Inspect Suite makes just about anything possible. The all-in-one solution allows you to import CAD data and acquire measuring data regardless of the system. It supports you in 3D printing and reverse engineering and assists you in inspection and evaluation. It's the established standard in 3D metrology that simplifies and speeds up your workflow.

Index Features Anything, anywhere: the portable solution • Lightweight, compact 3D laser scanner • Travel-friendly to support you on the spot • Assists you in confined spaces and difficult-to-reach areas Easy to use, ready to use • Stand-alone device • Ready to start in no time • Easy, intuitive scanning process

Index Features Integrated photogrammetry for large objects • Take the scanner to the object: flexible use on large or heavy objects Multiple laser sources adapting to your needs • Two available laser sources: red and blue • Captures data on many surfaces and materials • Suitable for dark and shiny objects, deep pockets and small details • Enhanced precision for scanning parts up to multiple meters • Highly reliable results

Index Features Three scanning modes at the push of a button The flexible solution allows you to change modes within one single scan job. Red crosses for large areas Efficiently scan large sections or use it for fast 3D reconstruction Blue lines for fine details Suitable for small parts, details or for dark, shiny surfaces Single red line for confined areas For deep pockets or hard-to-reach areas

Ready for easy inspection Use a powerful solution consisting of optical scanning and GOM Inspect Suite software. • Easy and efficient surface inspection • Create a 3D visualization of any surface and see nominal data, actual status and deviations simultaneously • Assists your inspection of surface defects and many other needs

Move it: dynamic measurements You need to move the object while you scan it? Thanks to the dynamic measurement function your object can be repositioned during the scanning process. For your convenience: control buttons The operation is in your hands: navigate intuitively through the complete scanning procedure via control buttons on the scanner. Stay flexible: dynamic referencing With the new T-SCAN hawk, you can capture 3D data with high precision even on moving objects and in difficult ambient conditions including vibrations

The new T-SCAN hawk with GOM Inspect Suite assists you in maintenance, repair and overhaul. Wherever the job leads you, the portable solution travels with you in just one case. It helps you And defects and draw the right conclusions fast.

Made for manufacturers The new T-SCAN hawk with GOM Inspect Suite is the allin-one solution that puts industrial precision in your hands. Take it to molding and production areas or wherever it is needed, upgrade your quality control from tool to Anal part or fully digitize any object to create a digital twin.

Made for makers The new T-SCAN hawk with GOM Inspect Suite is your ideal partner for 3D metrology. The flexible hand-held solution supports you with tasks such as 3D printing, rapid prototyping or reverse engineering and gets you there faster and easier.

Index Applications Contact Reverse engineering v From shape to CAD v Archiving of tools and cultural heritage v Everything from small details to very large parts Maintenance >/ 3D inspection of wear and damage >/ Portable, indoor and outdoor >/ Trend analysis Quality control >/ Actual comparison with CAD >/ Functional dimensioning >/ Shop floor inspection

Video Teaser Made for those who are making, scanning and inspecting Dive into the world of the new T-SCAN hawk with GOM Inspect Suite. Click to play the video in your browser

Technical Data Contact Technical Data T-SCAN hawk Type / T-SCAN hawk Scanning area Detailed scan Deep pockets Built-in photogrammetry with optional internal photogrammetry
