Technical Information smiths detection bringing technology to life Feature Highlights • Mobile, flexible system • Insulated body • Incorporates HI-SCAN 8585 • Powerful X-ray generator (160 kV cp) • Penetration up to 31 mm steel (typical) • Film safe up to ISO 1600 / 33 DIN • Integrated power generator (option) • Air-conditioner ScanVan is a mobile X-ray inspection system using a self-propelled vehicle (van) with special interior fittings. The X-ray inspection system HI-SCAN 8585 is integrated. The ScanVan has been designed for places where luggage, freight or mail is loaded or unloaded and has to be checked for customs or security purposes. An insulated body and an installed air-conditioner and rapid heater ensure optimum operation in most climatic conditions. To establish operation at AC mains, an integrated power generator is incorporated as an option to supply the electrical devices independent of a mains source. Fast and easy loading and unloading of items to be inspected is guaranteed by means of a powerful motorized conveyor at the input side and a heavy duty roller conveyor at the output. Both of them can be folded up into the vehicle. The powerful X-ray generator (160kV cp) in combination with the sensitive detector system and the enhanced image processing system provide a penetration of up to 31mm steel (typical). Solid wires up to 0 0.1 mm (38 AWG) are typical detectable. The operator space is provided with all necessary equipment to control the scanning process, e.g. control desk, operator chair, monitor, keyboard. Additional options like an intercom system, video monitoring system are available.

HI-SCAN 8585 General Specifications Tunnel dimensions Max. object size Conveyor height 11 Conveyor speed at mains frequency 50 Hz / 60 Hz Max. conveyor load even distributed 200 kg (441 lbs) over the whole conveyor Conveyor system (refer to sheet 95588231 for more information) 853 (W) x 856 (H) [mm] • 33.6” (W) x 33.7” (H) 835 (W) x 835 (H) [mm] • 32.8” (W) x 32.8” (H) approx. 300 mm (11.8”) approx. 0.2 [m/s] Resolution (wire detectability) 31 Penetration (steel) 31 X-ray dose / inspection (typical) Film safety Duty cycle Anode voltage integrated feed-in conveyor (length approx. 470 mm (18.5”))...
