MAXI MATO R Maximum Pressure. High Pressure Technology • Testing Equipment Hydraulics • Pneumatics » Rental Units for liquids and gases.

MAXIMATOR worldwide, Rental Units for liquids and gases LS 1600 M189 LM 1600 GX170 LM 5000 G400 Nitrogen Charging Unit DLE75 GM 1600 DLE30 GM 2200 DLE75 Compact and lightweight units to generate high pressure levels for fluids and gases are used for a variety of applications. Parts and pressure equipment are pressure-tested, pressure measuring instruments are function-tested and calibrated, gas is compressed or transferred, liquids are injected into processes or membranes and bladder accumulators are charged with nitrogen. Compressed air driven power packs from Maximator are the perfect tool...

Maximator Power Packs Liquid can be used for many technical applications in engineering and industry. This units can be operated in Atex Zone 1 and comply with category 2G. They generate hydraulic pressures of up to 4,000 bar safely and inexpensively. They are driven via compressed air ranging from 1 to 10 bar. The advantages at a glance: • no electrical connection required for operation • all Power Packs can be used in explosion areas (ATEX II 2G IIB c Tx) • an extensive array of accessories for adaptation and pressure measuring • Control panels with logical design ensure safe operation Maximator...

• Working Pressure up to 1,500 bar • 3.1 calibrated gauges and transducers • Operating medium water • hand operation possible • Extensive range of accessories, also prepared for pressure recording • Stable flight case for safe transport The MAXIMATOR Power Pack Type LS1600 M189 is the ideal solution for mobile pressure generation. Weighing just 20 kg, it can generate up to 1,500 bar - even in hand operation. Accessories include adapters, pressure transducer and rupture disks.

Type: Order Code: Pressure Ratio: Working Pressure max.: Operating Media: Flow Capacity max.: Connection Air Drive Inlet PL: Connection Pressure Outlet P: Air Drive Pressure: Dimensions W x D x H: Dimensions Case W x D x H: Weight: Weight incl. Case: M189-01-VE-HL-4H Suction Filter 3/8“f BSPP SS NG15 Tank Stainless Steel 6,5 Litre Inlet Gland Shut off valve 65000psi 1/4“ Cross 4M / T-Piece 4M Safety head assambly 4M Pressure gauge 0-1600 bar 0100mm Air control unit C1 Safety Valve Bulkhead Coupling 22500psi 1/4“ Rupture Disc RD-22000

Pressure Transducer 0-1500 bar, 0-10V * Adapter : • 4M(a)->1/2“(f) BSPP; • 4M(a)->FNPT1/2“; • 4M(a)->1/4“(f) BSPP; • 4M(a)->FNPT1/4“ Cable Connection 3000 mm Air Drive Inlet: 1/4“ BSPP not to be used in explosion areas

Betriebsdruck/ Outlet Pressure (bar) Förderleistung/Flow (l/min) Betriebsdruck bei/Outlet Pressure at 6 bar Luftverbrauch bei/Air consumption at 4 bar Luftverbrauch bei/Air consumption at 8 bar Nur für/Only for MO 189: PBmax./Max.outlet pressure 1000 bar Betriebsdruck bei/Outlet Pressure at 4 bar Betriebsdruck bei/Outlet Pressure at 8 bar Luftverbrauch bei/Air consumption at 6 bar Prüfflüssigkeit/Test Liquid: Wasser-Öl-Emulsion/Water Oil Emulsion ca. 1 - 10 cst Performance Graph High Pressure Pump Type M189 Luftverbrauch/ Air consumption (lN/mi

Power Pack Type LM1600 GX170 • Working pressure up to 1,000 bar • 3.1 calibrated gauges and transducers • Operating medium water • Extensive range of accessories, also prepared for pressure recording • Stable flight case for safe transport The MAXIMATOR Power Pack Type LM1600 GX170 is designed for mobile pressure generation of up to 1,000 bar. Two pressure outlets with shut-off valves allow efficient t

Type: Order Code: Pressure Ratio: Working Pressure max.: Operating Media: Flow Capacity max.: Connection Air Drive Inlet PL: Connection Pressure Outlet P1-P2: Air Drive Pressure: Dimensions W x D x H: Dimensions Case W x D x H: Weight: Weight incl. Case: *other operating media on request 1 GX 170-V-6M 2 Suction Filter 1“f BSPP SS 6 2-Way angle valve 22500psi 3/8“ 7 Cross 6M / T-Piece 6M 9 Pressure Gauge 0-1600 bar 0100mm 10 Filter 1/2“ BSPP 11 Regulator 1/2“f BSPP (ATEX) 12 Shut off Valve 1/2“ BSPP 14 Safety valve 1/2“ 20 Bulkhead Coupling 22500psi 3/8“ 30 Hose 1500 mm 1000 Offshore frame 1001...

Power Pack LM 1600 GX170 Accessories Stainless Steel Tray Flightcase Hose Accessories Pressure Transducer 0-1500 bar, 0-10V * High Pressure Plug Type 21P6M Connections Air Drive Inlet: 1/2“BSPP Pressure Outlet P1/P2: 6M (9/16-18 UNF) Measurement Connection: 4M (7/16-20 UNF) Fluid Inlet: 1“(m) BSPP Pressure Release: *not to be used in explosion areas

Betriebsdruck/ Outlet Pressure (bar) Förderleistung/Flow (l/min) Betriebsdruck bei/Outlet Pressure at 4 bar Betriebsdruck bei/Outlet Pressure at 8 bar Luftverbrauch bei/Air consumption at 6 bar Betriebsdruck bei/Outlet Pressure at 6 bar Luftverbrauch bei/Air consumption at 4 bar Luftverbrauch bei/Air consumption at 8 bar Prüfflüssigkeit/Test Liquid: Wasser-Öl-Emulsion/Water Oil Emulsion ca. 1 - 10 cst Luftverbrauch/ Air consumption (lN/min) Performance Graph High Pressure Pump Type GX170

• Working pressure up to 4,000 bar • 3.1 calibrated gauges and transducers • Operating medium water • Extensive range of accessories, also prepared for pressure recording • Stable flight case for safe transport The MAXIMATOR Power Pack Type LM5000 G400 is designed for mobile pressure generation of up to 4,000 bar. Accessories include a 5 litre stainless steel canister, adapters and a pressure transducer.

Type: Order Code: Pressure Ratio: Working Pressure max.: Operating Media: Flow Capacity max.: Connection Pressure Inlet PL/A: Connection Pressure Outlet P1-P2: Air Drive Pressure: Dimensions W x D x H: Dimensions Case W x D x H: Weight: Weight incl. Case: *other operating media on request 1 G 400-2LVE-4H 2 Suction Filter 1/2“f BSPP 6 2-Way Angle Valve 65000psi 1/4“ 7 Cross 4M / T-Piece 4M 9 Pressure Gauge 0-6000 bar 0160mm 10 Filter 1/2“ BSPP 11 Regulator 1/2“f BSPP 12 Shut off valve 1/2“ BSPP 14 Safety valve 1/2“ 15 Stroke counter 20 Bulkhead coupling 65000psi 1/4“ 30 Hose 1500 mm 100 Stainless...
