Gunnebo Entrance Control
PreSec Automated Pre-Security Gate

PreSec Automated Pre-Security Gate

Product catalog summary

Overview: The Gunnebo PreSec is an automated pre-security gate designed for airports to interface with passenger flight information systems. It verifies the validity of boarding passes and other security credentials before passengers enter the security screening area.

Key Features:

Integrated reader and PC application for boarding pass validation.
Ergonomic design with a 10.1’ LCD display for passenger instructions.
Dense sensor array for fraud detection and passenger transit confirmation.
Optional upgrades for passport/document readers and biometric devices.

Technical Specifications:

Drive: Brushless DC digital servomotor.
Materials: AISI 304 stainless steel and tempered glass panels.
Operating Modes: Controlled entry, optional exit button, emergency mode.
Stacking Option: Allows continuous passenger flow up to 60 passengers per minute.
Passenger Sensors: 16 sensors for single person detection and safety compliance.
Controlling Unit: Gunnebo dedicated gate controller with remote control capabilities.
Connectivity: Modbus Protocol, RS232, USB, Ethernet, and HDMI options.
Display: 10.1’ WXGA LCD with touch screen option.
Status Lights: LED indicators for lane status and boarding pass presentation.

Benefits:

High passenger throughput and increased security.
Reduction in staffing costs and minimal space requirements.

Additional Features:

Walkway width options from 600mm to 900mm.
Power failure options: Fail Lock and Fail Safe.
Advanced detection for passenger safety with carry-on luggage.
Customizable settings through BGR GUI.

Technical Data:

Power Supply: 110/230Vac, 50/60Hz.
Operating Temperature: -5°C to 40°C.
IP Rating: IP 43.
Flow Rates: 10-12 passengers per minute in BCBP mode.
MCBF: 10 million cycles.

Compliance and Standards:

CE compliance with Machine Directive and EMC Directive.
Harmonized Norms: EN 60335-1, EN16005, EN 61000-6-4, EN 61000-6-2, EN ISO 12100.

Contact Information: For further details, contact Gunnebo Entrance Control at their UK office or visit their website.

Catalog excerpts

Gunnebo PreSec Automated Pre-Security Gate

Open the catalog to page 1

Operating Modes The Gunnebo PreSec is a pre-security gate developed for interfacing to the airports passenger flight information system and check the validity of the passenger entitlement to enter the security area. The integrated reader in conjunction with the application running on the integrated PC, will confirm that the boarding pass is valid for the day of travel, the availability of the flight and other specific security items to allow the passenger to proceed in their passage through the airport. The PreSec is located prior to the security before the traveller enters the security screening...

Open the catalog to page 2

Connectivity Gate • Modbus Protocol on RS232 • Digital I/O Embedded PC • 4 x RS232 • 4 x USB2.0 • LVDS and HDMI Video •2 x Ethernet LCD Colour Display • 10.1' WXGA 800x1280 resolution • Elegant thin housing, with embedded status light • Touch screen option available • Entry leg and central position options Walkway width from 600mm to 900mm 165 mm width cabinet footprint Plain or sloped entry leg options available Power Failure: Fail Lock and Fail Safe options available Torque-limited breakthrough option available (for fail-lock version) Advanced detection for reliable passenger safety even with...

Open the catalog to page 3

Site Preparation Concrete Base to specification at least (cube) 300N/mm² of resistance. Base to be flat and level to +/- 5mm over footprint area.

Open the catalog to page 4

International Standards CE compliance meeting the following • 2006/42/EC Machine Directive • 2004/108/EC EMC Directive Harmonized Norms • EN 60335-1 (2002) Safety of Household appliances and special electrical appliances • EN16005 (2012) Safety in use of powered pedestrian doors • EN 61000-6-4 (2002) Electromagnet compatibility - generic standard, emission • EN 61000-6-2 (2002) Electromagnet compatibility - generic standard, immunity • EN ISO 12100 (2010) Safety of households and similar electrical appliances For further information please contact: Gunnebo Entrance Control The Gate House Ashdown...

Open the catalog to page 5

Take advantage of our knowledge: www.gunnebo.com/Entrance-Control Design and production: Gunnebo. Photos Credits: Gunnebo and Fotolia. The data given in this material may be subject to change without further notice. The Gunnebo logos and “Gunnebo – For a safer world” are registered trademarks of Gunnebo AB.

Open the catalog to page 6
