PCD and Solid Carbide Cutting Tools

DrillStraight-Flute Drill Series ■ AeroDrill101 pag. 10 Reamin SC-Drill Series ■ AeroDrill D10 pag. 62

Production plants and R&D facilities in Europe and North America enable Cruing to supply tested and award winning products worldwide. WINNER V* M or 2013 » INNOVATION AWARDS Universitat Stuttgart Cphbg Holz-Berufsgenossenschaft Cf DGUV Test \DNV-QL II COMPANY WITH QUALITY SYSTEM CERTIFIED BY DNV GL = ISO 9001 =

Cruing is one of the most important groups for diamond cutting tools and works closely with many of the world's leading aerospace manufacturers, F1 racing teams and luxury yacht builders.

Air Cooled Dry Cutting The Aerotech® System is a revolutionary tooling solution that thoroughly evacuates hot dust particles produced during cutting operations. By effectively air cooling the material and cutter, it significantly reduces machining temperatures. This allows manufacturers of composite parts to consider dry cutting their components, providing a practical alternative to machining with coolants. 10 years in the field First launched in 2008, the Aerotech® System has a proven track record of precision and absolute reliability in demanding tier 1 production environments producing CFRP...

Dust Free Machining Health and Safety standards at the workplace advise that dust created through machining processes should be reduced at source and must fall within the Workplace Exposure Limits (WEL), this is where the Aerotech® System can help. By capturing the dust at the point of cut and evacuating it directly into the CNC extraction shroud the Aerotech® will greatly reduce, or even eliminate, airborne dust that would otherwise pollute the work cell and contaminate the air.

Aero Drill Drilling solutions for perfect holes Cruing AeroDrill series offers unique designs for PCD Straight and Twist drills, Countersinks and One-shot drill and countersinks. Unique uninterrupted PCD point Special drill point geometry and side profile Many leading producers of CFRP parts for the Aerospace industry have already qualified Cruing drills and are benefitting from the performances of one of the most cost-effective drills available today. See the difference that the new AeroDrill 101-Uni provides on unidirectional CFRP. Cutting edge optimized for unidirectional and woven CFRP Enhanced...

Programme Drilling Technical Number of cutting edges Helix angle Application Hand-held Hand-held CNCdr i ll i ng CNCdr i ll i ng CNCdr i ll i ng CNCdr i ll i ng counters i nki ng counters i nki ng [integral pilot) [interchangeable pilot) Tool body Solid carbide Solid carbide Solid carbide Solid carbide Steel Available with through coolant CNC one-shot drilling CNC one-shot drilling CNC one-shot drilling & countersinking & countersinking & countersinking Tool body Solid carbide Solid carbide Solid carbide Available with through coolant

Technical features: ■ High density PCD cutting edges: 2 ■ Solid carbide straight fluted body ■ Diameters range: from 3,0 to 20,0 mm ■ Through coolant from 4,00 mm Through coolant on request Applications: ■ For CNC automated drilling of CFRP and hard composite materials

Technical features: ■ High density PCD cutting edges: 2 ■ Solid carbide twist body ■ Diameters range: from 2,5 to 4,0 mm ■ Through coolant from 4,00 mm Through coolant on request Applications: ■ For CNC automated drilling of CFRP and hard composite materials

Technical features: ■ High density PCD cutting edges: 2 ■ Solid carbide twist body ■ Diameters range: from 4,76 to 10 mm ■ Through coolant from 4,00 mm Through coolant on request Applications: ■ For CNC automated drilling of CFRP and hard composite materials

Technical features: ■ High density PCD cutting edges: 3 ■ Solid carbide twist body coolant ■ Diameters range: from 3,0 to 10,0 mm ■ For CNC automated drilling of CFRP and hard composite materials ■ Extended tool-life and lower delamination ■ Available with through coolant from 4,0 mm diameters

Technical featuress: ■ HSS body ■ High density PCD cutting edges: 2/3 coolant ■ Pilot diameters from 2.5 to 8.0 mm on request ■ Shank form: thread (metric or imperial) ■ Diameters: from 10.00 to 31.75 mm on request ■ Available with customized pilot ■ Hard composites/metallic stack materials

Technical featuress: ■ PCD cutting edges: 2/3 ■ Pilot diameters hole: from 2,5 to 4,77 mm ■ Shank form: thread ■ For hand-held drifting of CFRP and hard composite/ metallic stack materials ■ With integral [801] or interchangeable [802] pitot ■ Avaifabfe with customised pilot on request Through coofant on request

Aero Mill High-performance milling Cruing AeroMill series offers PCD cutters designed for milling CFRP, composites and light alloys. No chatter and vibration Increased edge retention No delamination Super-fine surface finish Low Ra values Solid-carbide or heavy metal tungsten alloy body With external and internal coolant supply 22 AeroMill series covers the complete range of cutting tools commonly used within the Aerospace and composite industries. Edge milling, ball-nose and face milling solutions, all qualified by leading manufacturers cutting CFRP parts. AeroMill cutters are also available...

Application CNC pre-finishing CNC pre-finishing CNC edge CNC edge CNC edge CNC finishing CNC finishing CNC finishing S large volume S large volume finishing S inside finishing S inside finishing S inside removal removal corner rounding corner rounding corner rounding Technical design Tool body Heavy metal Solid carhide Heavy metal Heavy metal Heavy metal Heavy metal Solid carhide Heavy metal tungsten alloy Solid carhide tungsten alloy tungsten alloy tungsten alloy tungsten alloy Solid carhide tungsten alloy Available with through coolantAir cooled dry cutting (with Aerotech System) Page CNC slotting...

Technical features: ■ Heavy metal tungsten alloy body ■ High density PCD cutting edges: 2/3 ■ Diameters range: from 6,35 to 12,7 mm Applications: ■ For CNC automated cutting of CFRP, aluminium and light alloy materials ■ Particularly indicated for finishing operations ■ Customised finishing cutters available on request
